IEC_62133-2 21A_620e_FDIS Small Cell And Battery Equipment With Calibration Certificate

IEC_62133-2 21A_620e_FDIS Small Cell And Battery Safety Information Provided With Ingestion Hazards Information

8.2 Small cell and battery safety information

Small cells and batteries and equipment using small cells and batteries are to be provided with information regarding ingestion hazards. Small cells and batteries that may pose an ingestion hazard are those that can fit within the limits of the ingestion gauge shown in Figure 3.

The following warning language is to be provided with the information packaged with the small cells and batteries or equipment using them:

• Keep small cells and batteries which are considered swallowable out of the reach of

children.

• Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can

occur within 2h of ingestion.

• In case of ingestion of a cell or battery, seek medical assistance promptly.

Dimensions in millimetres

NOTE This gauge defines a swallowable component and is defined in ISO 8124-1.

                    Figure 3 – Ingestion gauge

IEC_62133-2 21A_620e_FDIS Small Cell And Battery Equipment With Calibration Certificate. Kingpo builds this as a complete test station: chamber or fixture, control system, safety interlocks and data capture, so that the abuse or performance test in the applicable standard can be run and documented without building the rig yourself.

What it does

• Reproduces the condition named in the standard (thermal, mechanical, electrical or environmental)
• Holds the setpoint within the tolerance the standard allows
• Records the run and retains the data for the test report
• Protects the operator: abuse testing is hazardous by design

Specification

How a test run works

1. Confirm the standard, clause and sample preparation your market requires.
2. Set the profile: setpoint, ramp rate, dwell and number of cycles.
3. Load the sample, close the interlocks and start the run.
4. Monitor through the viewing window or camera; do not open the chamber during an abuse test.
5. Export the run data and attach it to the test report.

Buying notes

Battery abuse testing scales with cell size and energy. Tell us the largest cell or pack you will test, the standard you test to, and whether you need the chamber to be explosion-proof — those three answers decide the model more reliably than the product name.

Frequently asked questions

Can the chamber be customised?

Yes. Dimensions, temperature range, penetration fixtures and data interfaces are all configurable.

Is installation included?

We provide installation guidance and commissioning support remotely; on-site service is available.

Is calibration included?

Yes, a calibration certificate is supplied with the unit.

Related gauges and equipment

Other equipment in the same range:

• E27-7006-22C-1 Gauge I For Checking Side-Contact Resiliency In Lampholders
• E14 lamp cap gauge - Not go gauge for E14 caps on finished lamps - 7006-28B-1
• E40 Lamp cap gauge - Go gauges for screw threads of lampholders E40 - 7006-25-7
• E40 Lamp cap gauge - Plug gauge for lampholders for testing protection against accidental contact E40 - 7006-24-3
• IEC 60968-Figure 3 Test Arrangement For Bending Moment Imparted By The Lamp At The Lampholder
• E40 Lamp Cap Gauge For Testing Contact - Making In Lampholders E40-7006-23-3

Send the standard, figure number and quantity to Kingpo technical sales for a quotation and delivery date.
